Product Overview
Simrad AC70 Autopilot Computer
Model: 000-10186-001AC70 Drive computer for rudder or propeller (i.e. Voith Schneider) for reversible motor or galvanic non-isolated solenoids.
Specifications| 12/24 V in | |
| DRIVE | Output for Motor or solenoid command |
| DRIVE ENGAGE | Output for clutch/bypass valve or automode signal for oil flow valve etc |
| ALARM | Output for external alarm buzzer |
| NMEA 0183 | in/out for IEC 61162-1, -2 and NMEA 0183 |
| RUDDER | Input for frequency rudder feedback |
| REMOTE | Input for NFU steering lever |
| MODE | Input for external mode selector |
| SIMNET | Connection to CAN network |
What's in the Box:
- AC70 Course Computer
- N2K Power Cable including 120 ohm Terminator
- N2K Terminator Male
- N2K Cable - 0.6m (2ft)
- N2K T-Joiner
