Product Overview
Garmin Signalâ„¢ RM 100 Remote Station
Model: 010-02952-00
Â
- WORKS WITH GARMIN SIGNAL VHF RADIOS VIA THE GARMIN BLUENETâ„¢ NETWORK
- INTERCOM LINKS REMOTE STATION AND NETWORKED HEAD UNITS
- BRIGHT 3.5-INCH COLOR TOUCHSCREEN DISPLAY
- MODERN EDGE-TO-EDGE GLASS DESIGN
- COMPACT FORM FACTOR AND REDUCED MOUNTING DEPTH
- INCLUDES FIST MIC AND BUILT-IN ADAPTIVE NOISE CANCELLATION
Â
The Garmin Signal RM 100 remote station lets you control your compatible VHF marine radio from a secondary helm or flybridge. Enjoy remote control access to VHF, DSC, AIS and other Garmin Signal VHF radio functions with this premium fixed-mount remote station.
Â
Control VHF, DSC, AIS and other radio functions from a secondary helm or flybridge. The intercom feature enables communication between remote station and networked head units.
Â
Featuring an edge-to-edge glass design and bright 3.5-inch color touchscreen display, it looks great installed at your helm, and the form factor matches the Garmin Signal VHF marine radios.
Â
Specifications
Â
| General | Head Unit: 75 x 160 x 29 mm (3.0" x 6.3" x 1.2") |
| Weight | Head Unit: 0.53 lb (240 g) |
| Operating voltage | 9.6 - 32 VDC |
| Water rating | IPX7 |
| Display Type | color IPS LCD, capacitive touch |
| Display Size | 3.5" (89 mm) |
| Display resolution | 640 x 480 pixels |
| Backlight | 1,000 nits |
| Multi-language interface | yes |
| Electrical Features | |
| Typical current draw at 12 Vdc | Head Unit: 400 mA, 1.8 A max |
| Compass-safe distance | Head Unit: 70 cm (27.6") |
| Networking & Connections | |
| Garmin Marine Network | GMN 1.0/2.0 |
What's in the Box:
- Garmin Signalâ„¢ RM 100 head unit
- Fist mic
- Sun cover
- Remote station power and external audio cable with fuse (2 m)
- Fist mic power cable with fuse (2 m)
- Cable for Garmin BlueNetâ„¢ network (6 m)
- Mounting hardware
- Mounting template
- Documentation
